【課程綱要】

【課程內容】

Why Need ESD Testing in Scientific Industries?

   (科技產業為何需要 ESD測試？)

• •AECQ Reliability Test for Auto. Industries
• (針對汽車工業的AECQ ESD可靠度測試)

Component-level ESD Testing
(科技產業零組件級ESD測試)

1. •Introduction of ESD and EOS (ESD與EOS簡介)
2. •HBM/MM/CDM Testing & Standards (AEC-Q100 included)(HBM/MM/CDM 測試與規範 (包含AECQ-Q100))
3. •ESD Comparisons in Component Level
4. (各零組件級 ESD測試比較)
5. •ESD Testing Procedures  (ESD測試程序)
6. •Cases Study  (案例探討)

Transmission Line Pulse Testing
(科技產業零組件級傳輸線脈衝測試)

1. •TLP Standard &Testing
2.  (TLP規範與測試)
3. •Comparisons of ESD and TLP  (ESD與TLP測試比較)
4. •Cases Study  (案例探討)

System-level ESD Testing
(科技產業系統級ESD測試)

1. •System HBM Testing & Standards (AEC-Q200 included)
2. (系統級HBM測試與規範 (包含AECQ-Q200))
3. •ESD Testing Procedure in the System HBM
4. (系統級HBM的ESD測試程序)
5. •System Board-level CBM
6. (系統板級CBM測試)
7. •ESD Comparisons of Component/System Levels
8. (零組件/系統級 ESD測試比較)
9. •Cases Study  (案例探討)

Nature of ESD Damage and Failure Analysis

 (ESD破壞本質與失效分析)

1. •ESD Damages by Component HBM/MM/CDM
2. (零組件級 HBM/MM/CDM ESD傷害)
3. •ESD Damages by System HBM/CBM
4. (系統級HBM/CBM ESD傷害)
5. •ESD Failure Analysis and Procedure
6. (ESD失效分析與程序)
7. •Cases Study  (案例探討)

• Summary (課程總結)
